Electric Outboard Motors
Designed to be quiet for environmentally sensitive waters, these 1HP horsepower Electric Outboard Motors provides plenty of power for trolling and primary propulsion. Conventional construction and design provides trusted reliability.
• Motor: Water-cooled brushless,High efficiency ,Water coooled at motor base
• Voltage: 48 Volts DC,or 60 VDC.
• Maximum Current: 50 Amps DC for 1HP Version,Max.current 100Amp for 2 HP version
• Designed for salt water or fresh water use
Configuration: 1. 5KW/10KW BLDC MOTOR Liquid Cooling System 487V/72V/96V/120V Available 2.BLDC CONTROLLER Liquid Cooling System HPC300H/500H/700H 48V/72V/96V/120V Avaliable 3. Outboards witn options of short/long shaft Efficiency over 90% Long life over 20000h 4. HP options: 6HP, 10HP, 15HP, 20HP Available 5. Package Measurement: 1360cm x 72cm x 50cm
EPO SERIES Available Models (Long Shaft / Short Shaft): EPO-06H EPO-10HP EPO-15HP EPO-10HP EPO-20HP
|
| Model:Dolphin 1 HP Tiller Short Shaft &Model Dolphin 2HP tiller short shaft |
 |
|
Shaft Length: 25.88 inches (660 mm) DC Volt Meter: Included on Cover Weight: 10.4 kg. Blade Diameter = 190 MM (7.45inches)
|
 |
Shaft Length: 15 inches (381 mm) DC Volt Meter: Included on Cover Weight: 65 pounds |
| Model: 4 HP Tiller Short Shaft |
|
Shaft Length: 15 inches (381 mm) DC Volt Meter: Included on Cover Weight: 65 pounds |
| Model: 4 HP Tiller Short Shaft |
 |
Shaft Length: 20 inches (508 mm) DC Volt Meter: Included on Cover Weight: 67 pounds
|
| Model: 4 HP Remote Control Short Shaft |
 |
Shaft Length: 15 inches (381 mm) DC Volt Meter: Included on Cover Remote Throttle Control: Included with 20 ft cable Remote Steering Brackets: Included in Box Weight: 72.6 pounds including Remote Throttle and Cable
|
| Model: 4 HP Remote Control Long Shaft |
 |
Shaft Length: 20 inches (508 mm) DC Volt Meter: Included on Cover Remote Throttle Control: Included with 20 ft cable Remote Steering Brackets: Included in Box Weight: 75 pounds including Remote Throttle and Cable
|
| Model: Classic Transom-Mount Motors |
 |
รุ่น classic : 28
|
| Model: Endura Transom-Mount Motors |
 |
รุ่น edura : 30 |
รุ่น edura : 40 |
Model: PowerDrive Bow-Mount Motors |
 |
รุ่น : 40 PD (V2) |
รุ่น : 50 PD |
