Horizontal Axis Wind Turbine      JOC-WG(10KW)
HORIZONTAL AXIS WIND TURBINE

VERTICAL AXIS WIND TURBINE
JOC-WG(10kW)

JOC-WG(20kW)


JOC-WG-200W
JOC-WG-300W JOC-WG-1000W JOC-WG-10kW



Description
Rated output power :    10kw
Maximum power :   15kw
Startup wind speed:     10m/s
Startup wind speed:    3m/s
Working wind speed:    4-25m/s
Safe wind speed:         50m/s
Rated rotate speed:       90r/min
Blade diameter:         8m
Wording voltage:       DC240-500V/AC220V/380V
Blades material X number:   Reinforced    fibber   glass X 3
Speed regulation:     Yawing+electro  magnetic

Generator type:

3-phase AC PM
Tower heigt:      10m
Stop method:   Brake by Hand drag
Main machine weigh:    800kg
Dragline tower:     90kg
Independent tower: 1300kg
Annual generationMin/Max:  10000/30000kwh
