One/two independent network operation
One master with 2 network segment ports
Max. 200m x 2 communication distance under 6Mbps
Jumper selectable band rate: 3M/6M/12M bps transfer rate
Full and half duplex transfer mode are jumper selectable
On board memory
Programmable timer interrupt
RJ45 phone jack for easy installation
LED diagnostic
PCI local b us specification Re v. 2.1 compliance
Master controller ASIC
32KB SRAM
Full/Half duplex, RS-422 with transformer isolation
Transfer speed: 6Mbps
PCB Dimensions: 176 (L) x 107 (W) mm
Operating Temperature: 0 to 70?C
Storage Temperature: -20 to 80?C
Power Consumption: +5V @500 mA typical
Pin Assignment
Windows 98/NT/2000/XP DLL DDE Server
Linux Driver
Link Master Utility
ISaGRAF Driver
LabView Driver
Weight: 152g
